- Characteristics :
Omnidirectional Conductivity (XYZ Conductivity): A unique conductive adhesive ensures ultra-low impedance in both vertical and horizontal directions.
Superior Shielding Performance: Provides up to 80dB - 100dB of shielding effectiveness in the 10MHz to 1GHz frequency range.
High Toughness and Tear Resistance: The plain weave structure makes it resistant to breakage during bending and winding, perfectly conforming to irregularly shaped surfaces.
Environmental Stability: The surface nickel layer offers excellent oxidation and corrosion resistance, preventing tarnishing over long-term use.
Easy Processing: Easy to die-cut into various shapes, with no adhesive overflow and clean cut edges.
- Application:
Consumer Electronics: FPC (Flexible Printed Circuit) sheathing inside smartphones, laptops, and tablets.
Communication Equipment: Sealing gaps in 5G base station shielding cabinets to prevent signal leakage.
Automotive Electronics: Wiring harness shielding for navigation systems and intelligent driving sensors.
Display Technology: Grounding of LCD/OLED display backlight components.
Medical Equipment: Ensuring high-precision diagnostic instruments are protected from environmental electromagnetic interference.
- Product Features:
- Parameters :
Name
Parameter
Testing instruments and methods
Weight
130g±10g
GB/T4669-1995
Thickness
0.12mm±0.01mm
EZ/T01003-1991
Width
±1mm
GB/T4667-1995
Fabric Density
230T±10
/
Substrate Density
45g/m2±10
GB/T4669-1995
Product Density
75g/m2±10
GB/T4669-1995
Shielding Effectiveness
80dB-100dB（10MHz-1GHz）
SJ20524-1995
Salt Spray Test (5% 48h 35℃)
<0.06Ω/Sq
ASTM B117-03
Wet and Dry Test (60℃ 90% 300h)
≥4%
JIS C 7022
Surface Resistance
<0.06Ω/Sq
ASTM F390
Metallic Layer Adhesion
≥4级
AATCC TM8-2001
Peel Strength
≥1.2Kgf/in
PSTC 1 Mod
Retention Strength
≥48h
PSTC 7 Mod
